Large Longi Mono Solar Panels 450w Mono Bifacial LR4 72HPH 450M Wholesale

Products Description

Electrical Characteristics STC : AM1.5 1000W/m² 25°C NOCT:AM1.5 800W/m² 20°C 1m/s Test uncertainty for Pmax:土3%

Module Type	LR4-72HPH-445M	LR4-72HPH-450M	LR4-72HPH-455M	LR4-72HPH-460M	LR4-72HPH-465M
Testing Condition	STC NOCT	STC NOCT	STC NOCT	STC NOCT	STC NOCT
Maximum Power (Pmax/W)	445 334.3	450 338.0	455 341.8	460 345.5	465 349.3
Open Circuit Voltage (Voc/V)	49.1 46.2	49.3 46.4	49.5 46.5	49.7 46.7	49.9 46.9
Short Circuit Current (Isc/A)	11.53 9.35	11.60 9.41	11.66 9.46	11.73 9.51	11.79 9.56
Voltage at Maximum Power (Vmp/)	41.3 38.4	41.5 38.6	41.7 38.8	41.9 39.0	42.1 39.2
Current at Maximum Power (Imp/A)	10.78 8.70	10.85 8.75	10.92 8.81	10.98 8.86	11.05 8.91
Module Efficiency/(%)	20.5	20.7	20.9	21.2	21.4

---

Operating Parameters

---

Operational TemPerature	-40°C - +85°C
Power Output Tolerance	0-3%
Voc and Isc Tolerance	土3%
Maximum System Voltage	DC1500V (IEC/UL)
Maximum Series Fuse Rating	20A
Nominal Operating Cell Temperature	45土2°C
Protection Class	Class II
Fire Rating	UL type 1or2 IEC ClassC

---

Mechanical Loading

---

Front Side Maximum Static Loading	5400Pa
Rear Side Maximum Static Loading	2400Pa
Hailstone Test	25mm Hailstone at the speed of 23m/s

---

Temperature Ratings (STC)

---

Temperature Coefficientof Isc	+0.050%/°C
Temperature Coefficientof Voc	-0.265%/°C
Temperature Coefficient of Pmax	-0.340%/°C

---

Specification

---

item	value
place of Origin	China Jiangxi
Brand Name	LONGI
Model Number	LR4-72HPH-450M
Cell size	166mmx166mm
Type	Half Cell
Panel Efficiency	20.7%
Certificate	CE
Warranty	25 Years

---

Product advantages

100% Inspection

Before and After Lamination. Most stringent acceptance criteria and tightest tolerance, Intelligent alarm and stop mechanism in case of any deviation or errors.

100% EL Testing
Before and Following Lamination Ensure "Zero" micro crack monitoring before final Inspection, Continuous line monitoring and video/photo record for each cell and panel.

100% Optimal Testing
Ensure 3% Positive Power Tolerance Comprehensive QC information management system with barcode ID, Quality traceable system in place to allow quality data flow
constantly.

100% Cells Sorting
Ensure Colour and Power Difference.Ensure high yields, consistent performance and durability, First of 52 steps strict quality control and inspection process.
