    800w Deye Solar Micro Inverter 33.5A 60Hz SUN-M80G3-EU-Q0

    Ask Lasest Price
    Brand Name : Deye
    Model Number : SUN-M80G3-EU-Q0
    Supply Ability : 100 Piece/Pieces per Week
    Price : $169.00/pieces 1-49 pieces
    • Product Details
    • Company Profile

    800w Deye Solar Micro Inverter 33.5A 60Hz SUN-M80G3-EU-Q0

    800w Inverter Deye micro inverter 800w SUN-M80G3-EU-Q0 solar inverter

    Product Description
    800w Deye Solar Micro Inverter 33.5A 60Hz SUN-M80G3-EU-Q0

    Specification


    SUN-M60/80/100G3-EU-Q0 is a new generation grid-connected micro inverter with intelligent networking and monitoring system to ensure maximum efficiency. The SUN-M60/80/100G3-EU-Q0 is optimized to efficiently accommodate today's high output photovoltaic modules with up to 500W output and dual MPPT. At the same time, it supports fast shutdown applications to ensure the safety of your investment.


    Model
    SUN-M60G3-EU-Q0
    SUN-M80G3-EU-Q0
    SUN-M100G3-EU-Q0
    Input Data (DC)
    Recommended input Power (STC)210-400W (2 Pieces)210-500W (2 Pieces)210-600W (2 Pieces)
    Maximum input DC Voltag60V
    MPPT Voltage Range25-55V
    Operating DC Voltage Range20-60V
    Max. DC Short Circuit Current2x19.5A
    Max input Current2x13A
    Number of MPPT/Strings per MPPT2/1
    Output Data (AC)
    Rated output Power600W
    Rated output Current2.7A2.6A3.6A3.5A4.5A4.4A
    Nominal Voltage/Range (this may vary with grid standards)220V/ 0.85Un-1.1Un230V/ 0.85Un-1.1Un220V/ 0.85Un-1.1Un230V/ 0.85Un-1.1Un220V/ 0.85Un-1.1Un230V/ 0.85Un-1.1Un
    Nominal Frequency/Range50/60Hz
    Extended Frequency/Range45-55Hz/55-65Hz
    PowerFactor>0.99
    Maximum units per branch865
    Efficiency
    CECWeighted Efficiency95%
    Peak Inverter Efficiency96.5%
    Static MPPT Efficiency99%
    Night Time Power Consumption50mW
    Mechanical Data
    Ambient Temperature Range-40-65°C
    Size (mm)212Wx230Hx40D (Without mounting bracket and cable)
    Weight(kg)3.5
    CoolingNatural cooling
    Enclosure Environmental RatingIP67
    Features
    CompatibilityCompatible with 60-72 cell PV modules
    CommunicationPower line/WIFI/Zigbee
    Grid Connection StandardENS0549-1, VDE0126-1-1, VDE 4105, ABNT NBR 16149, ABNT NBR 16150, ABNT NBR 62116, RD1699, UNE 206006 IN, UNE 206007-1 IN, IEEE1547
    Safety EMC/StandardUL 1741, IEC62109-1/-2, IEC61000-6-1, IEC61000-6-3, IEC61000-3-2, IEC61000-3-3
    Warranty10 years
    800w Deye Solar Micro Inverter 33.5A 60Hz SUN-M80G3-EU-Q0
    800w Deye Solar Micro Inverter 33.5A 60Hz SUN-M80G3-EU-Q0
    800w Deye Solar Micro Inverter 33.5A 60Hz SUN-M80G3-EU-Q0
    800w Deye Solar Micro Inverter 33.5A 60Hz SUN-M80G3-EU-Q0
    800w Deye Solar Micro Inverter 33.5A 60Hz SUN-M80G3-EU-Q0
    800w Deye Solar Micro Inverter 33.5A 60Hz SUN-M80G3-EU-Q0
    800w Deye Solar Micro Inverter 33.5A 60Hz SUN-M80G3-EU-Q0
    800w Deye Solar Micro Inverter 33.5A 60Hz SUN-M80G3-EU-Q0

    Product Features


    - Zigbee or WIFI communication


    - Support reactive power compensation


    - Quick shutdown function


    - IP67 protection level, 10-year warranty


    - 2 MPP tracker, module-level monitoring


    Packing & Delivery
    800w Deye Solar Micro Inverter 33.5A 60Hz SUN-M80G3-EU-Q0
    To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
    Company Profile

    800w Deye Solar Micro Inverter 33.5A 60Hz SUN-M80G3-EU-Q0


    Fuzhou Thinmax is a solar company located at the city Fuzhou which is the capital of Fujian province. We have about 50 office colleagues and 100 factory colleagues. With the professional colleagues and over 10 years experience of dealing with solar system, we are able to provide 100% satisfying service for customers. Not only for the ready products but also the customized products. In order to make the ship more fluently. We have cooperated with more than 20 shipping companies. After customers place the order. We will always choose the cheapest and reliable one to arrange the shipment. When customers have received the items. We have professional technician ready for customers if they have any problems.
    800w Deye Solar Micro Inverter 33.5A 60Hz SUN-M80G3-EU-Q0
    Why Choose Us
    800w Deye Solar Micro Inverter 33.5A 60Hz SUN-M80G3-EU-Q0
    800w Deye Solar Micro Inverter 33.5A 60Hz SUN-M80G3-EU-Q0
    FAQ

    Q1: What is the delivery time?

    A1: It's according to the model. We will ship the items within 3 days if the items in stock.
    Q2: What ways of payment do you accept.
    A2: We can accept LC, Paypal, Credit card, etc.
    Q3: Will you provide shipping sevice?
    A3: Yes. We will choose the best shipping way and shipping company for the customers according to the demands.
    Q3: What if we have problems after sale?
    A4: Don't worry. We have professional technicians ready for our customers who can take care of the problems.
    Q5: What is the minimum quantity?
    A5: We can send a sample to you. If you are satisfied with our products and service. Please place larger quantity to us.
    Q6: Are the inverters original?
    A6: Yes. Of course. If it's not. We will return all money back to you.
