ARK 48v Lithium Ion Solar Battery LFP 25.6kwh Growatt Lithium Battery High Voltage ARK 25.6H-A1 HV

FUZHOU THINMAX SOLAR CO., LTD
Contact Now
    Buy cheap ARK 48v Lithium Ion Solar Battery LFP 25.6kwh Growatt Lithium Battery High Voltage ARK 25.6H-A1 HV from wholesalers

    Buy cheap ARK 48v Lithium Ion Solar Battery LFP 25.6kwh Growatt Lithium Battery High Voltage ARK 25.6H-A1 HV from wholesalers
    • Buy cheap ARK 48v Lithium Ion Solar Battery LFP 25.6kwh Growatt Lithium Battery High Voltage ARK 25.6H-A1 HV from wholesalers

    ARK 48v Lithium Ion Solar Battery LFP 25.6kwh Growatt Lithium Battery High Voltage ARK 25.6H-A1 HV

    Ask Lasest Price
    Brand Name : Growatt
    Certification : ce
    Model Number : ARK 25.6H-A1 HV
    Supply Ability : 100 Piece/Pieces per Week
    Price : $9,445.00/pieces 1-4 pieces
    • Product Details
    • Company Profile

    ARK 48v Lithium Ion Solar Battery LFP 25.6kwh Growatt Lithium Battery High Voltage ARK 25.6H-A1 HV

    ARK 48v Lithium Ion Solar Battery LFP 25.6kwh Growatt Lithium Battery High Voltage ARK 25.6H-A1 HV
    Product Description
    ARK 48v Lithium Ion Solar Battery LFP 25.6kwh Growatt Lithium Battery High Voltage ARK 25.6H-A1 HV
    ARK 48v Lithium Ion Solar Battery LFP 25.6kwh Growatt Lithium Battery High Voltage ARK 25.6H-A1 HV
    ARK 48v Lithium Ion Solar Battery LFP 25.6kwh Growatt Lithium Battery High Voltage ARK 25.6H-A1 HV

    ARK series batteries use cobalt-free lithium iron phosphate cells, and can provide various flexible solutions such as single-phase/three-phase, hybrid/AC coupling, and reserve energy storage according to the needs of different scenarios. With the use of the inverter and the multi-level protection provided by the BMS, it can ensure that the ARK battery has super safety and reliability, excellent user experience, and longer life. In addition, the ARK battery adopts a modular stacking design and is light in weight, which can be installed independently by a single person, saving users more time and money.


    ARK 48v Lithium Ion Solar Battery LFP 25.6kwh Growatt Lithium Battery High Voltage ARK 25.6H-A1 HVARK 48v Lithium Ion Solar Battery LFP 25.6kwh Growatt Lithium Battery High Voltage ARK 25.6H-A1 HV

    Product Features

    easy installation

    - Can be installed independently by one person

    - Modular stackable design

    - Automatic recognition of battery modules

    - IP65 protection level, can be placed outdoors


    Safe and reliable

    - Cobalt-free lithium iron phosphate battery

    - High cycle stability, long life

    - Soft start, the system is protected from surge

    - System Warranty


    Intelligent monitoring operation and maintenance

    - Automatic brown-out wake-up

    - Remote diagnosis, upgrade



    Specification


    Growatt Battery

    ARK2.5LARK5.1LARK7.6LARK10.2LARK12.8L
    Battery ModuleARK2.5-A1 (2.56KWH,51.2V,28KG)
    Number of Modules12345

    Energy capacity

    2.56KWH5.12KWH7.68KWH10.24KWH12.8KWH
    Usable capacity2.30KWH4.6KWH6.9KWH9.21KWH11.52KWH

    Dimension (W*D*H)

    650/260/185mm

    650/260/365mm

    650/260/545mm650/260/725mm650/260/905mm

    Weight

    28KG56kg84kg112kg140kg
    Standard Charge/Discharge Current25A50A75A100A100A

    Growatt Battery

    ARK15.3LARK17.9LARK20.4LARK23.0LARK25.6L

    Battery Module

    ARK2.5-A1 (2.56KWH,51.2V,28KG)
    Number of Modules6

    7

    8910
    Energy capacity15.36KWH17.92KWH20.48KWH23.04KWH25.64KWH

    Usable capacity

    13.81KWH16.12KWH18.43KWH20.73KWH23.04KWH

    Dimension (W*D*H)

    650/260/1085mm650/260/1265mm650*260*1445mm650*260*1625mm650*260*1805mm
    Weight168kg196kg224kg252kg280kg
    Standard Charge/Discharge Current100A100A100A100A100A
    General

    Battery type

    Gobalt Free Lithium Iron Phosphate(LFP)
    Nominal Voltage51.2V
    Operating voltage range47.2-56.8V

    IP Protection

    IP65
    InstallationWall-Mounted or Floor Installation*1
    Operation Temperature-10-50°C*2
    Features
    BMS Monitoring ParametersSOC,System Voltage,current, cell voltage,cell temperature, PCBA temperature measurement
    Communication PortgCAN
    Warranty: 5 years /10 yearsYes/optional
    CertificationIEC62619 (Cell&Pack), CE, CEC, RCM, UN38.3

    ARK 48v Lithium Ion Solar Battery LFP 25.6kwh Growatt Lithium Battery High Voltage ARK 25.6H-A1 HV

    Packing & Delivery
    ARK 48v Lithium Ion Solar Battery LFP 25.6kwh Growatt Lithium Battery High Voltage ARK 25.6H-A1 HV
    To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
    Company Profile
    Fuzhou Thinmax is a solar company located at the city Fuzhou which is the capital of Fujian province. We have about 50 office colleagues and 100 factory colleagues. With the professional colleagues and over 10 years experience of dealing with solar system, we are able to provide 100% satisfying service for customers. Not only for the ready products but also the customized products. In order to make the ship more fluently. We have cooperated with more than 20 shipping companies. After customers place the order. We will always choose the cheapest and reliable one to arrange the shipment. When customers have received the items. We have professional technician ready for customers if they have any problems.
    FAQ
    Q1: What is the delivery time?
    A1: It's according to the model. We will ship the items within 3 days if the items in stock.
    Q2: What ways of payment do you accept.
    A2: We can accept LC, Paypal, Credit card, etc.
    Q3: Will you provide shipping sevice?
    A3: Yes. We will choose the best shipping way and shipping company for the customers according to the demands.
    Q3: What if we have problems after sale?
    A4: Don't worry. We have professional technicians ready for our customers who can take care of the problems.
    Q5: What is the minimum quantity?
    A5: We can send a sample to you. If you are satisfied with our products and service. Please place larger quantity to us.
    Q6: Are the inverters original?
    A6: Yes. Of course. If it's not. We will return all money back to you.
